9.6.3 Cabin lights
The cabin light switch is located above the corner cupboard in the cabin.
Figure 1. Yamarin 88 DC
cabin light switch
| 1 | Heater control panel |
| 2 | Led strip switch |
| 3 | Cabin ceiling lights switch |
| 4 | Toilet light switch |
| 5 | Toilet fan switch |
